Honda CBR1000RR 2006 User Manual

〜
(1)
(2)
(3)
(1) SEL button
(2) RESET button
(3) Tachometer needle
36
Gauges, Indicators & Displays
Instruments & Controls
Presetting the Shift Indicator and
Selecting the Display
To set the shift indicator:
Press and hold the SEL button ( ), then
turn on the ignition switch. Keep the
SEL button pressed in until the initial
display is completed. The tachometer
needle moves to its preset position.
Push and hold the RESET button for more
than 1 second, the tachometer needle will
move by an increment of 1,000 rpm.
When the needle exceeds the allowable
range, it will automatically return to 4,000
rpm.
After completing the selection, press the
SEL button, and proceed to the selecting
the display for the indicator.
You may select the rpm activation point
(in the 4,000 rpm to 12,200 rpm range) for
the shift indicator and select the display
used to alert you.
Each time you press the RESET button
( ), the tachometer needle ( ) will
move by an increment of 250 rpm. (In
the 12,000 rpm 12,200 rpm range,
the increment is 200 rpm.)
1.
2.
1
23
05/11/25 12:17:35 31MEL620_045

Honda CBR1000RR 2006 Specifications

General

Engine Type	Liquid-cooled inline four-cylinder
Displacement	998 cc
Compression Ratio	12.2:1
Fuel System	PGM-DSFI electronic fuel injection
Transmission	6-speed
Front Brakes	Dual radial-mounted four-piston calipers with 320mm discs
Rear Brakes	Single 220 mm disc
Front Tire	120/70ZR-17
Rear Tire	190/50ZR-17
Fuel Capacity	18 liters (4.8 gallons)
Bore x Stroke	75mm x 56.5mm
Max Power	172 hp @ 11, 250 rpm
Ignition	Computer-controlled digital transistorized with 3-D mapping
Final Drive	O-ring-sealed chain
Front Suspension	43mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability
Rear Suspension	Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability
Seat Height	32.3 inches (820mm)
Curb Weight	199 kg (439 lbs)
