(1)
(2)
(1) coolant temperature indicator
(2) malfunction indicator lamp (MIL)
27
Gauges, Indicators & Displays
Instruments & Controls
Coolant Temperature Indicator and
Malfunction Indicator Lamp (MIL)
Continuing to ride with an overheated
engine can cause serious engine damage.
The coolant temperature indicator ( ) and
the malfunction indicator lamp (MIL) ( )
light when the coolant temperature reaches
252°F (122°C). At the same time, the
numbers in the coolant temperature meter
display start flashing.
If this occurs, stop the engine and check
the reserve tank coolant level. Read pages
and do not ride the
motorcycle until the problem has been
corrected.
1
111 114
2
05/11/25 12:16:16 31MEL620_036

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honda CBR1000RR 2006 and is the answer not in the manual?

Honda CBR1000RR 2006 Specifications

General IconGeneral
Engine TypeLiquid-cooled inline four-cylinder
Displacement998 cc
Compression Ratio12.2:1
Fuel SystemPGM-DSFI electronic fuel injection
Transmission6-speed
Front BrakesDual radial-mounted four-piston calipers with 320mm discs
Rear BrakesSingle 220 mm disc
Front Tire120/70ZR-17
Rear Tire190/50ZR-17
Fuel Capacity18 liters (4.8 gallons)
Bore x Stroke75mm x 56.5mm
Max Power172 hp @ 11, 250 rpm
IgnitionComputer-controlled digital transistorized with 3-D mapping
Final DriveO-ring-sealed chain
Front Suspension43mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability
Rear SuspensionUnit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability
Seat Height32.3 inches (820mm)
Curb Weight199 kg (439 lbs)
