Clip Removal
Servicing Your Honda
Clip removal and installation:
Press down on the center pin to release
the lock.
Pull the clip out of the hole.
Push the bottom of the pin.
Insert the clip into the hole.
Lightly press down on the center pin to
lock the clip.
Removal
Installation
1.
2. 3.
1.
2.
3.
1. 2.
1.
2.
05/11/25 12:25:59 31MEL620_106

Honda CBR1000RR 2006 Specifications

General

Engine Type	Liquid-cooled inline four-cylinder
Displacement	998 cc
Compression Ratio	12.2:1
Fuel System	PGM-DSFI electronic fuel injection
Transmission	6-speed
Front Brakes	Dual radial-mounted four-piston calipers with 320mm discs
Rear Brakes	Single 220 mm disc
Front Tire	120/70ZR-17
Rear Tire	190/50ZR-17
Fuel Capacity	18 liters (4.8 gallons)
Bore x Stroke	75mm x 56.5mm
Max Power	172 hp @ 11, 250 rpm
Ignition	Computer-controlled digital transistorized with 3-D mapping
Final Drive	O-ring-sealed chain
Front Suspension	43mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability
Rear Suspension	Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability
Seat Height	32.3 inches (820mm)
Curb Weight	199 kg (439 lbs)
