Honda CBR1000RR 2006 User Manual

(1) VIN
(1)
LEFT SIDE
202
Serial Numbers
Vehicle Identification
Technical Information
The frame, VIN, and engine serial
numbers are required when you register
your motorcycle. They may also be
required when ordering replacement parts.
You may record these numbers in the
Quick Reference section at the rear of this
manual.
The VIN (vehicle identification number)
appears on the Safety Certification Label
attached to the left side of the frame.
05/11/25 12:41:06 31MEL620_211

Honda CBR1000RR 2006 Specifications

General

Engine Type	Liquid-cooled inline four-cylinder
Displacement	998 cc
Compression Ratio	12.2:1
Fuel System	PGM-DSFI electronic fuel injection
Transmission	6-speed
Front Brakes	Dual radial-mounted four-piston calipers with 320mm discs
Rear Brakes	Single 220 mm disc
Front Tire	120/70ZR-17
Rear Tire	190/50ZR-17
Fuel Capacity	18 liters (4.8 gallons)
Bore x Stroke	75mm x 56.5mm
Max Power	172 hp @ 11, 250 rpm
Ignition	Computer-controlled digital transistorized with 3-D mapping
Final Drive	O-ring-sealed chain
Front Suspension	43mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability
Rear Suspension	Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability
Seat Height	32.3 inches (820mm)
Curb Weight	199 kg (439 lbs)
