Honda CBR1000RR 2006 User Manual

145
Drive Chain
Servicing Your Honda
An endless (riveted master link) chain
connects the countershaft and rear wheel
sprockets. The O-ring chain uses rubber
rings between the side plates of the pin
and roller links to seal in the
manufacturer-installed lubricating grease
and keep out moisture and dirt.
Under severe usage, or when the
motorcycle is ridden in unusually dusty or
muddy areas, more frequent maintenance
will be necessary.
The service life of the chain depends on
proper lubrication and adjustment. Poor
maintenance can cause premature wear or
damage to the drive chain or sprockets.
The drive chain should be checked,
adjusted, and lubricated as part of the pre-
ride inspection (page ).
Before servicing your drive chain, turn the
engine OFF, lower the side stand, and
check that your transmission is in neutral.
It is not necessary to remove or replace the
drive chain to perform the recommended
service in the Maintenance Schedule.
49
05/11/25 12:33:07 31MEL620_154

Honda CBR1000RR 2006 Specifications

General

Engine Type	Liquid-cooled inline four-cylinder
Displacement	998 cc
Compression Ratio	12.2:1
Fuel System	PGM-DSFI electronic fuel injection
Transmission	6-speed
Front Brakes	Dual radial-mounted four-piston calipers with 320mm discs
Rear Brakes	Single 220 mm disc
Front Tire	120/70ZR-17
Rear Tire	190/50ZR-17
Fuel Capacity	18 liters (4.8 gallons)
Bore x Stroke	75mm x 56.5mm
Max Power	172 hp @ 11, 250 rpm
Ignition	Computer-controlled digital transistorized with 3-D mapping
Final Drive	O-ring-sealed chain
Front Suspension	43mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability
Rear Suspension	Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability
Seat Height	32.3 inches (820mm)
Curb Weight	199 kg (439 lbs)
