Honda CBR1000RR 2006 User Manual

9
Instruments & Controls
Instruments & Controls
This section shows the location of all
gauges, indicators, and controls you would
normally use before or while riding your
motorcycle.
The items listed on this page are described
in this section. Instructions for other
components are presented in other sections
of this manual where they will be most
useful.
(cont’d)
..........Operation Component Locations . 11
..............Gauges, Indicators & Displays . 14
......................Multi-function Display . 22
..............Coolant Temperature Meter . 23
PGM-FI Indicator and
..Malfunction Indicator Lamp (MIL) . 25
Low Oil Pressure Indicator and
..Malfunction Indicator Lamp (MIL) . 26
Coolant Temperature Indicator and
..Malfunction Indicator Lamp (MIL) . 27
HESD Indicator and
..Malfunction Indicator Lamp (MIL) . 28
......................................Speedometer . 29
...........................................Odometer . 29
...............................Tripmeter A & B . 31
.....................................Digital Clock . 32
05/11/25 12:14:07 31MEL620_018

Honda CBR1000RR 2006 Specifications

General

Engine Type	Liquid-cooled inline four-cylinder
Displacement	998 cc
Compression Ratio	12.2:1
Fuel System	PGM-DSFI electronic fuel injection
Transmission	6-speed
Front Brakes	Dual radial-mounted four-piston calipers with 320mm discs
Rear Brakes	Single 220 mm disc
Front Tire	120/70ZR-17
Rear Tire	190/50ZR-17
Fuel Capacity	18 liters (4.8 gallons)
Bore x Stroke	75mm x 56.5mm
Max Power	172 hp @ 11, 250 rpm
Ignition	Computer-controlled digital transistorized with 3-D mapping
Final Drive	O-ring-sealed chain
Front Suspension	43mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability
Rear Suspension	Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability
Seat Height	32.3 inches (820mm)
Curb Weight	199 kg (439 lbs)
