NFS2-3030 Listing Document — P/N LS10006-051NF-E:F2 5/19/2022 37
LCD Programming
Selecting the LCD Display option on the first Panel Programming screen will display the following LCD Display options:
BRIGHTER: Press to increase contrast on the display. The intensity will
increase by approximately 5% with each press of the key.
DARKER: Press to decrease contrast on the display. The intensity will decrease
by approximately 5% with each press of the key.
LANGUAGE: Press this soft key to choose the language that will display on the
LCD. (i.e.
ENGLISH, HEBREW, PORTUGUESE, SPANISH, etc.)
BACKLIGHT: Press this soft key to select one of the following backlighting
options:
ON EXCEPT AC FAIL, OFF, or ON. When On Except AC Fail is
selected, the backlight will turn off when the power supply experiences AC
failure. Default: On
DEFAULT: Press to set the factory default setting (40%).
CURRENT: Press to select the intensity that was in effect when the screen was
accessed.
ACS Programming
Selecting the ACS Programming option on the first Panel Programming screen will display the following ACS programming options:
Consider the following when programming ACS devices:
• The NFS2-3030 ACS circuit can accommodate up to 32 annunciator devices, or if expanders are used, a total of 3,072 annunciator points.
• Smoke Control devices must be set as FSCS or HVAC annunciator types. In addition to its 64 smoke control points, when an SCS device is
operating in FSCS (Firefighters Smoke Control Station) mode, there are 32 additional points which function as alarm points. They can be mapped
to a zone or point to send the SCS device into a fire alarm state when any of the additional 32 points is activated. Any of the 32 alarm points that
are used must be set to MONITOR mode from the panel. Any of these points that are not used can be set to NONE. Refer to the SCS manual for
further information on Smoke Control devices.
• UDACT/UDACT-2 and TM-4 communicators, and the UZC Zone Coder are installed on the same EIA-485 ACS circuit as annunciators, and are
included with annunciator programming.
• The TM-4 occupies one of the 32 annunciator addresses
• The UDACT or UDACT-2 can occupy one or more annunciator addresses.
• The UZC can occupy up to four annunciator addresses 64 points each.
• When the UDACT/UDACT-2 or UZC expand beyond one annunciator address, 64PT should be used for the subsequent address types, and the
annunciator addresses should be sequential. Other than address assignment, there is no ACS point programming for these devices.
ANNUNCIATOR TYPE: Move the cursor to the desired annunciator address and
press this key to scroll through the available annunciator types.
POINT PROGRAMMING: Press to proceed to the ACS Point Programming
screen.
LCD Display Screen
LCD PROGRAMMING
LCD INTENSITY: 50%
BRIGHTER DEFAULT
DARKER CURRENT
LANGUAGE: ENGLISH ACCEPT
BACKLIGHT ON EXCEPT AC FAIL BACK
ACS Programming Screen
ACS PROGRAMMING
A01:64PT A02:64SYS A03:96PT A04:TM4
A05:UDACT A06:96SYS A07:FSCS A08:UZC
A09: NO A10: NO A11: NO A12: NO
A13: NO A14: NO A15: NO A16: NO
A17: NO A18: NO A19: NO A20: NO
A21: NO A22: NO A23: NO A24: NO
A25: NO A26: NO A27: NO A28: NO
A29: NO A30: NO A31: NO A32:AMG
ANNUNCIATOR TYPE ACCEPT
POINT PROGRAMMING BACK
Type Used for
64PT 64 point annunciation
64SYS 64 point annunciation, with first 8 points reserved
64SVC
1
1 Two Level Bypass: When an ACS board is programmed as a 64SVC or
96SVC type, the operator must enter the Program/Alter Status mode of
operation before pressing any push buttons to control points on these boards.
If a push button is pressed while not in the Program/Alter Status screen, and
no unacknowledged events exist, the password screen will automatically be
displayed so the operator can enter the Program/Alter Status mode.
64-point service mode for Two Level Bypass
96PT 96 point annunciation
96SYS 96 point annunciation, with first 8 points reserved
96SVC
1
96-point service mode for Two Level Bypass
96DCC 96 point annunciation to be used with multiple Command Centers
UDACT UDACT or UDACT-2, first address. Any additional UDACT or
UDACT-2 annunciator addresses should be programmed as
64PT and be sequential.
TM4 TM-4
AMG
2
2 AMG Addressing: When using an AMG, the address it occupies (an address
of 25 through 32, typically address 32) must be set to annunciator type AMG,
and address one must be set to annunciator type 64PT.
AMG
FSCS Smoke control modules set for FSCS mode
HVAC Smoke control modules set for HVAC mode
UZC Universal Zone Coder, first address. Any additional UZC
annunciator addresses should be programmed as 64PT and be
sequential.
