NFS2-3030 Listing Document — P/N LS10006-051NF-E:F2 5/19/2022 47
Detector Sensitivity Settings
The following is a table of detector sensitivity settings by detector type:
SUP L(DUCTL) supervisory Y Y Laser smoke detector used as a duct detector to report supervisory condition
rather than alarm.
SUP T(DUCTL) supervisory N Y Laser smoke detector used as a duct detector to report supervisory condition
rather than alarm.
FIRE/CO fire Y Y Combination Photoelectric/CO detector
F/CO (P SUP)
1
fire Y (See Note
below)
Y Combination Photoelectric/CO detector. Photo element activation generates a
supervisory condition.
F/CO (C SUP) fire Y (See Note
below)
Y Combination Photoelectric/CO detector. CO element activation generates a
supervisory condition.
Note: For Fire/CO detectors:
Detectors programmed as F/CO (P SUP), the Heat and CO elements will latch and require a system reset to clear. The Photo element will latch or
track, depending on the Fire/CO (Photo SUP) setting. Refer to “FIRE
/CO (PHOTO SUP) LATCHING” on page 34.
Detectors programmed as F/CO (C SUP), the Heat and Photo elements will latch and require a system reset to clear. The CO element will latch or
track, depending on the Fire/CO (CO SUP) setting. Refer to “FIRE
/CO (CO SUP) LATCHING” on page 34.
PHOTO/CO Fire Y Y PHOTO CO detector.
P/CO (P SUP) PHOTO-
Supervisory
CO- Alarm
Y (See note
below)
Y PHOTO CO detector
P/CO (C SUP) PHOTO- Fire
CO-
Supervisory
Y Y PHOTO CO detector
CO Alarm CO Alarm Y Y CO detector
CO SUP Supervisory Y (See note
below)
Y CO detector
Note: PHOTO/CO and CO Detectors programmed as PHOTO/CO (P SUP)/CO (CO SUP) will either latch or track, depending on the setting.
AIR REF fire Y Y Assign to one or more FSL-751detectors used to monitor the quality of air entering
the protected area. The air quality measurement allows the VIEW system to
compensate for vehicle fumes, fog, or other particles brought into the protected
area through the ventilation system. Poor air quality will lower the sensitivity of all
FSL-751 detectors on the SLC. The detector sensitivity, however, remains within
approved limits (always less than 1% obscuration per foot).
Note: A reference detector still functions as a smoke detector, but the detector sensitivity level should be set to the least sensitive level—AL:9 and PA:9
Alarm and Pre-Alarm sensitivity. Refer to “Detector Sensitivity Settings” on page 47 for a complete list of detector sensitivity settings.
HEAT fire Y Y 190
o
F heat detector
HEAT+ fire Y Y 190
o
F heat detector with low temperature warning
HEAT(FIXED) fire Y Y 135
o
F intelligent thermal sensor
HEAT (ROR) fire Y Y 15
o
F per minute rate-of-rise detector
SMOKE ACCLIM fire Y Y Combination Photoelectric/heat detector
SMOKE(ACCLI+) fire Y Y Combination Photoelectric/heat detector with low temperature warning, or
Intelliquad FSC-851 Photoelectric Multi-Criteria Smoke Sensor.
SMOKE(MULTI)
4
fire Y Y Multi-sensor smoke detector
SMOKE(BEAM) fire Y Y Beam Smoke Detector
ACCL(P SUP) fire Y (See note
below)
Y Combination Photoelectric/Heat detector. Photo element activation generates a
supervisory condition.
ACCL+(P SUP) fire Y (See note
below)
Y Combination Photoelectric/Heat detector with low temperature warning. Photo
element activation generates a supervisory condition.
Note: For ACCL/ACCL+ detectors:
Detectors programmed as ACCL (P SUP) or ACCL+(P SUP), the Heat element will latch and require a system reset to clear. The Photo element will
latch or track, depending on the ACCL (P SUP) Latching setting. Refer to ACCL
(P SUP) LATCHING on page 34.
1 When a device associated with a FAAST device is disabled locally, all devices associated with that FAAST will automatically be disabled as well.
2 Use only with approval of AHJ
3 Not suitable for Canadian applications
4 CLIP Mode only
Type Code Point Type Latching
Activates
CBE
Device/Point Function
Table 4 Intelligent Detector Type Codes (2 of 2)
