NFS2-3030 Listing Document — P/N LS10006-051NF-E:F2 5/19/2022 59
Trouble Zone Programming
Selecting a trouble zone (ZT001 through ZT100) in the Point Select of the Point Programming screen allows for a trouble equation to be written. Pro-
gramming options for the trouble zone are the same as a logic zone. In additions to basic point or zone variables, the programmer can add node offline
troubles to the equation. Place the cursor in the desired position and use the format “NO###”, where “###” equals the network node number to be
monitored for offline status.
POINT SELECT can not be used for this option.
System Troubles
The following table lists possible System Troubles that can be used in Logic Equation/Trouble Zone programming. The System Trouble index number
can be used as an argument in equation building.
System
Trouble
Index
System Trouble Name
System
Trouble
Index
System Trouble Name
System
Trouble
Index
System Trouble Name
System
Trouble
Index
System Trouble Name
0 GROUND FAULT 1 AC FAIL 2 BATTERY 3 CLASS A POS LOOP 1
4 CLASS A POS LOOP 2 5 CORRUPT LOGIC EQUAT 6 LCD80 SUPERVISORY 7 EPROM ERROR
8 INTERNAL RAM ERROR 9 EXTERNAL RAM ERROR 10 PROGRAM CORRUPTED 11 NO DEV INST ON L1
12 PANEL DOOR OPEN 13 AUXILIARY TROUBLE 14 RESERVED 15 ANNUN 1 TROUBLE
16 ANNUN 1 NO ANSWER 17 ANNUN 2 TROUBLE 18 ANNUN 2 NO ANSWER 19 ANNUN 3 TROUBLE
20 ANNUN 3 NO ANSWER 21 ANNUN 4 TROUBLE 22 ANNUN 4 NO ANSWER 23 ANNUN 5 TROUBLE
24 ANNUN 5 NO ANSWER 25 ANNUN 6 TROUBLE 26 ANNUN 6 NO ANSWER 27 ANNUN 7 TROUBLE
28 ANNUN 7 NO ANSWER 29 ANNUN 8 TROUBLE 30 ANNUN 8 NO ANSWER 31 ANNUN 9 TROUBLE
32 ANNUN 9 NO ANSWER 33 ANNUN 10 TROUBLE 34 ANNUN 10 NO ANSWER 35 ANNUN 11 TROUBLE
36 ANNUN 11 NO ANSWER 37 ANNUN 12 TROUBLE 38 ANNUN 12 NO ANSWER 39 ANNUN 13 TROUBLE
40 ANNUN 13 NO ANSWER 41 ANNUN 14 TROUBLE 42 ANNUN 14 NO ANSWER 43 ANNUN 15 TROUBLE
44 ANNUN 15 NO ANSWER 45 ANNUN 16 TROUBLE 46 ANNUN 16 NO ANSWER 47 ANNUN 17 TROUBLE
48 ANNUN 17 NO ANSWER 49 ANNUN 18 TROUBLE 50 ANNUN 18 NO ANSWER 51 ANNUN 19 TROUBLE
52 ANNUN 19 NO ANSWER 53 ANNUN 20 TROUBLE 54 ANNUN 20 NO ANSWER 55 ANNUN 21 TROUBLE
56 ANNUN 21 NO ANSWER 57 ANNUN 22 TROUBLE 58 ANNUN 22 NO ANSWER 59 ANNUN 23 TROUBLE
60 ANNUN 23 NO ANSWER 61 ANNUN 24 TROUBLE 62 ANNUN 24 NO ANSWER 63 ANNUN 25 TROUBLE
64 ANNUN 25 NO ANSWER 65 ANNUN 26 TROUBLE 66 ANNUN 26 NO ANSWER 67 ANNUN 27 TROUBLE
68 ANNUN 27 NO ANSWER 69 ANNUN 28 TROUBLE 70 ANNUN 28 NO ANSWER 71 ANNUN 29 TROUBLE
72 ANNUN 29 NO ANSWER 73 ANNUN 30 TROUBLE 74 ANNUN 30 NO ANSWER 75 ANNUN 31 TROUBLE
76 ANNUN 31 NO ANSWER 77 ANNUN 32 TROUBLE 78 ANNUN 32 NO ANSWER 79 NETWORK FAIL PORT A
80 NETWORK FAIL PORT B 81 NETWORK FAILURE 82 ADV WALK TEST 83 CHARGER FAIL
84 GROUND FAULT LOOP 2 85 CLASS A NEG LOOP 1 86 CLASS A NEG LOOP 2 87 GROUND FAULT LOOP 1
88 RESERVED 89 RESERVED 90 PROG MODE ACTIVATED 91 LOADING...NO SERVICE
92 BASIC WALK TEST 93 NFPA 24HR REMINDER 94 NVRAM BATT TROUBLE 95 RESERVED
96 RESERVED 97 RESERVED 98 RESERVED 99 RESERVED
100 RESERVED 101 RESERVED 102 RESERVED 103 RESERVED
104 RESERVED 105 CLASS A ON LOOP 3 106 RESERVED 107 RESERVED
108 MAN EVAC INITIATED 109 MAN EVAC RECEIVED 110 RESERVED 111 RESERVED
112 RESERVED 113-175 RESERVED 176 GROUND FAULT LOOP 3 177 GROUND FAULT LOOP 4
178 GROUND FAULT LOOP 5 179 GROUND FAULT LOOP 6 180 GROUND FAULT LOOP 7 181 GROUND FAULT LOOP 8
182 GROUND FAULT LOOP 9 183 GROUND FAULT LOOP 10 184 CLASS A NEG LOOP 3 185 CLASS A NEG LOOP 4
186 CLASS A NEG LOOP 5 187 CLASS A NEG LOOP 6 188 CLASS A NEG LOOP 7 189 CLASS A NEG LOOP 8
190 CLASS A NEG LOOP 9 191 CLASS A NEG LOOP 10 192 CLASS A POS LOOP 3 193 CLASS A POS LOOP 4
194 CLASS A POS LOOP 5 195 CLASS A POS LOOP 6 196 CLASS A POS LOOP 7 197 CLASS A POS LOOP 8
198 CLASS A POS LOOP 9 199 CLASS A POS LOOP 10 200 RESERVED 201 BUZZER OFF-LINE
202 RESERVED 203 RESERVED 204 RESERVED 205 RESERVED
206 PRINTER PAPER OUT 207 PRINTER OFF LINE 208 RESERVED 209 RESERVED
210 MANUAL MODE ENTERED 211 NCM COMM FAILURE 212 CLASS B SHORT A LOOP 1 213 CLASS B SHORT B LOOP 1
214 CLASS B SHORT A LOOP 2 215 CLASS B SHORT B LOOP 2 216 CLASS B SHORT A LOOP 3 217 CLASS B SHORT B LOOP 3
218 CLASS B SHORT A LOOP 4 219 CLASS B SHORT B LOOP 4 220 CLASS B SHORT A LOOP 5 221 CLASS B SHORT B LOOP 5
222 CLASS B SHORT A LOOP 6 223 CLASS B SHORT B LOOP 6 224 CLASS B SHORT A LOOP 7 225 CLASS B SHORT B LOOP 7
226 CLASS B SHORT A LOOP 8 227 CLASS B SHORT B LOOP 8 228 CLASS B SHORT A LOOP 9 229 CLASS B SHORT B LOOP 9
230 CLASS B SHORT A LOOP
10
231 CLASS B SHORT B LOOP 10 232 RESERVED 233 CLASS A SHORT LOOP 1
234 CLASS A SHORT LOOP 2 235 CLASS A SHORT LOOP 3 236 CLASS A SHORT LOOP 4 237 CLASS A SHORT LOOP 5
238 CLASS A SHORT LOOP 6 239 CLASS A SHORT LOOP 7 240 CLASS A SHORT LOOP 8 241 CLASS A SHORT LOOP 9
242 CLASS A SHORT LOOP 10 243 NCM COM FAILURE 244 RESERVED 245 RESERVED
246 RESERVED 247 RESERVED 248 RESERVED 249 RESERVED
250 SELF TEST FAILED 251 NETWORK
INCOMPATIBILITY
252 RESERVED 253 NETWORK MAP LIMIT
EXCEEDED
254 INVALID NODE TYPE 255 DISPLAY NODE LIMIT
EXCEEDED
256-383 RESERVED 384 REMOTE DISPLAY 1
TROUBLE
Table 9 System Trouble Names and Codes
