LOCAL MODE: Toggle between Local Mode (ON) or no Local Mode (OFF). During communication loss between the panel and its LCM/LEMs, SLC
devices selected for Local Mode participation (ON) will continue to function across all the panel’s SLCs in a limited manner. Input points will activate
output points of the same point type designations. For example, SLC inputs with “fire” point types will activate SLC outputs with “fire” point types.
Refer to Table 6 for monitor module point type information.
4-20 DEVICE SETUP: FMM-4-20module only: Displays the FMM-4-20 device setup screen. (Refer to page 50) This field appears only when
FMM-420 appears as the module’s Type Code label.
MORE: Press to display the third Module Point Programming screen.
WATERFLOW DELAY: When the WATERFLOW DELAY option is set to 0, water-
flow events are immediately reported to the panel upon activation. If a non-zero
value is entered in the
WATERFLOW DELAY, activation of a waterflow event is
delayed for the duration of that time. The waterflow event will have to remain
active for the duration of the delay. If the waterflow event does not remain
active for the entire delay duration, the waterflow event will not be reported to
the panel. Default: 0. Range: 0-60 seconds
ZONE MAP: Up to 10 zones. Press to display the Zone Map screen and modify
zone programming. (Refer to “
ZONE MAP” on page 45 for an illustration).
During initial programming, the primary zone (position 1) displayed is associ-
ated with the loop the device is installed on. In the example, the device’s default
programming set the primary zone as Z003, indicating that the device is
installed on Loop 3. Certain zone map positions are used for specific functions.
• Position 1: Use to link zone label to detector and for group zone disable.
• Position 3-7: FMM-4-20 module only: These positions are assigned to FMM-4-20 threshold levels 1 - 5 respectively. (Threshold levels are user-
programmed.See below.) Each will activate only if the device is currently at that threshold level. Once the device leaves that threshold level, the
zone in its corresponding CBE position will remain active or deactivate according to whether its threshold is programmed for latching or tracking.
4-20 DEVICE SETUP: Press the 4-20 Device Setup key to access the follow-
ing 4-20 module options.
4MA SCALE VALUE: Enter the 4 mA value.
20MA SCALE VALUE : Enter the 20 mA value.
UNITS: Enter the kind of units (5 spaces).
HYSTERESIS: Enter the hysteresis value in decimals as a percentage of the
overall 4 to 20 mA range. Default: 0
THRESHOLD SETUP: Press to display the Threshold Setup screen to access the
following 4-20 module threshold options.
THRESHOLD NUMBER: Enter the threshold number (1 - 5) that will be described
in this screen.
THRESHOLD VALUE: Enter the value for this threshold. (Threshold value is
represented in the unit type specified on the FMM-4-20 Device Setup Screen.)
EVENT: Select the event type that will generate when this threshold is reached.
Selections are
NO EVENT, TROUBLE, FIRE, SUPERVISORY, SECURITY, NON-
FIRE, and CRITICAL PROCESS.
TROUBLE TYPE: Select a trouble type for this threshold: TROUBLE 1, TROU-
BLE 2, or DEVICE INHIBIT. Device Inhibit will generate a trouble when the
FMM-4-20 is in a self-calibration state.
EVENT TRIGGER: Select LOWER LEVEL (values are falling), UPPER LEVEL
(levels are rising), or
SAME LEVEL.
TRACKING/LATCHING: Select TRACKING or LATCHING for the threshold trouble. If more than one threshold has been programmed as latching, the
first threshold reached will be the one that is latched.
Control Module Point Programming
With CONTROL selected as the module type, pressing the MORE key will display the following control module programming options:
NOTE: The panel setting LCM LOCAL MODE must be set to YES for local mode to work at the device level.
Module Point Programming Screen - Monitor (3)
MODULE POINT PROGRAMMING
L03M150
WATERFLOW DELAY:30
ACCEPT
BACK
FMM-4-20 Device Setup Screen
MODULE POINT PROGRAMMING
L03M150
4MA SCALE VALUE: 0.00
20MA SCALE VALUE: 2000.00
UNITS: PPM
HYSTERESIS: 02.0% ACCEPT
THRESHOLD SETUP BACK
Threshold Setup Screen
MODULE POINT PROGRAMMING
L03M150
THRESHOLD NUMBER 1
THRESHOLD VALUE: 500.25 PPM
EVENT TROUBLE LATCHING
TROUBLE TYPE: TROUBLE1 ACCEPT
EVENT TRIGGER: LOWER LEVEL BACK
