SCS Series Manual — P/N 15712:L 7/18/16 205
Read Status Special Applications
C.4 Read Status
The NFS2-3030 or NCA-2 can read status of the SCS-8L which is connected to it. It is accessed through the keypad of the local panel.
Figure C.4 shows the display and descriptions of the fields when a switch group is in time out trouble.
Figure C.4 Read Status Display Example 1: Switch Group in Time Out Trouble
• Annunciator/Point address. Address range to be displayed.
• Annunciator label. User-programmed 40-character text label for the SCS.
• SCS status. Status of the smoke control system: NORMAL; COMM LOSS; DIP SW DEFAULT; MODE CONFIG; EXPANDER
CONFIG; EXTERNAL TROUBLE.
See n“FSCS Module Trouble” on page 62 or “HVAC Module Trouble” on page 73.
• Switch-group label. User-programmed 40-character text label for the switch group.
• Switch-group number. Displays the switch group number.
• Toggle-switch position. Configuration of the selected switch group: AUTO, ON/OPEN, OFF/CLOSED.
• Annunciator point designation. List of up to four points associated with the selected switch group.
• Annunciator point type. Identifies whether the designated point is a control or monitor point.
• Switch-group enhanced trouble type. Status of the selected switch group: NORMAL, DEVICE MISMATCH, DEVICE TROUBLE,
DIP SW MISMATCH, TIME OUT. See “FSCS Toggle Switch Group Trouble” on page 63 or “HVAC Toggle Switch Group Trouble”
on page 74.
• Point state. ON, OFF.
• Point status. Status of points P01-P04 of the selected switch group.
– CON modules status: NORMAL, NO ANSWER; INVALID RESPONSE; MISMAT HDW TYPE; DISABLED.
– MON modules status: NORMAL, NO ANSWER; INVALID RESPONSE; MISMAT HDW TYPE; DISABLED;
OPEN CIRCUIT.
Figure C.5 shows the display and descriptions of the fields when the primary command node is in normal condition.
Figure C.5 Read Status Example 2: Primary Command Node Normal
• Group type. For FSCS Settings, see Table 3.5. For HVAC settings, see Table 3.10
• SCS mode. FSCS, HVAC.
• Mode type. Title of field displays the current SCS mode.
Annunciator Label
======== READ ADDRESS:A25P01-04 ========
ACS BOARD LABEL
STATUS: EXTERNAL TROUBLE
SG LABEL
SG01 STATUS: AUTO TIME OUT
P01 CON N003L03M100 OFF NORMAL
P02 CON N003L03M102 ON NORMAL
P03 MON N003L03M101 OFF NORMAL MORE
P04 MON N003L03M103 OFF NORMAL
====== 01:38:41P MON NOV 11, 2013=======
BACK
SCS Status
Switch-group Label
Toggle-switch
Position
Switch group‘s
Enhanced
Trouble Type
Switch-group Number
Point State
Point Address
Annunciator Point
Designation
Annunciator Point
Type
Point Status
Annunciator/Point
Address
Annuciator/Point Address
Group Type
======== READ ADDRESS:A25P01-04 ========
GROUP TYPE (1-5): 09
MODE (6): FSCS
FSCS (7): DEDICATED
DIPSWITCH SETTING: x1111110 / 7E
TROUBLE REPORTING DELAY: 30
========================================
BACK
SCS Mode
Mode Type
Dipswitch Setting
Trouble Reporting Delay
Binary
value
Hexadecimal
value
To Next Page
