137
Task Command
Display portal configuration and portal running state
information on an interface.
display portal interface interface-type
interface-number
Display portal authentication server information. display portal server [ server-name ]
Display portal Web server information. display portal web-server [ server-name ]
Display packet statistics for portal authentication
servers.
display portal packet statistics [ server server-name ]
Display portal user information.
display portal user { all | interface interface-type
interface-number }
Clear packet statistics for portal authentication
servers.
reset portal packet statistics [ server server-name ]
Portal configuration examples
Configuring direct portal authentication
Network requirements
As shown in Figure 40, the host is directly connected to the switch (the access device). The host is
assigned with a public IP address either manually or through DHCP. A portal server acts as both a portal
authentication server and a portal Web server. A RADIUS server acts as the authentication/accounting
server.
Configure direct portal authentication, so the host can access only the portal server before passing the
authentication and access other network resources after passing the authentication.
Figure 40 Network diagram
Configuration prerequisites
• Configure IP addresses for the host, switch, and servers as shown in Figure 40 and make sure they
can reach each other.
• Configure the RADIUS server properly to provide authentication and accounting functions.
Configuring the portal authentication server on IMC PLAT 3.20
In this example, the portal server runs on IMC PLAT 3.20-R2602P13 and IMC UAM 3.60-E6301.
1. Configure the portal authentication server:
