375
Configuring MFF
Overview
MAC-forced forwarding (MFF) implements Layer 2 isolation and Layer 3 communication between hosts
in the same broadcast domain.
An MFF enabled device intercepts ARP requests and returns the MAC address of a gateway (or server)
to the senders. In this way, the senders are forced to send packets to the gateway for traffic monitoring
and attack prevention.
As shown in Figure 117, ho
sts are connected to Switch C through Switch A and Switch B, which are called
Ethernet access nodes (EANs). The MFF enabled EANs forward packets from hosts to the gateway for
further forwarding. The hosts are isolated at Layer 2, but they can communicate at Layer 3.
An MFF-enabled device and a host cannot ping each other.
Figure 117 Network diagram for MFF
MFF works with any of the following features to implement traffic filtering and Layer 2 isolation on the
EANs:
• ARP snooping (see Layer 3—IP Services Configuration Guide).
• IP source guard (see "Configuring IP source guard).
• ARP detection (see "Configuring ARP attack protection")
.
• VLAN mapping (see Layer 2—LAN Switching Configuration Guide).
NOTE:
hen MFF works with static IP source guard entries, you must configure VLAN IDs in the static entries.
Otherwise, IP packets allowed by IP source
uard are permitted even if their destination MAC addresses
are not the MAC address of the gateway.
