1. Check the Version of the SNMP Module.

The HP AdvanceStack 10Base-T Hub in which the HP AdvanceStack

Router 210 Module is to be installed must also have an HP J2603B Eth-

ernet SNMP Module installed. (The router module will be mounted on

the SNMP module.) This SNMP module must be the HP J2603B version,

not the HP J2603A version.

If an SNMP module is already installed and you are not sure which ver-

sion it is, you can determine it in either of two ways:

By removing the cover plate from the hub’s Expansion Slot and look-

ing at the module (refer to the procedure below).

By using HP Stack Manager to display the version of the module

(refer to the procedure on page 1-7).

Looking at the SNMP Module

1. Using a Torx T-10 or flat-blade screwdriver, loosen the two captured

screws holding the cover plate over the hub’s Expansion Slot, then

remove the cover plate. Note that the screws are spring-loaded and

will release outward when unscrewed far enough. Do not unscrew

them completely from the cover plate.

Loosen these two screws

Figure 1-1. Cover Plate Screws

Installation

1. Check the Version of the SNMP Module.

1-5
