3. Install the Router Module.
The router module will be connected to the HP J2603B Ethernet SNMP
Module, and then the assembled modules will be installed in the
Expansion Slot in the back of the hub.
Note The HP Ethernet SNMP Module must be the HP J2603B version, not the
HP J2603A version. If an Ethernet SNMP module is already installed but
you are not sure which version it is, use either of the procedures under
“Check the Version of the SNMP Module”, page 1-5, to determine it.
WARNING Before installing the router module, unplug the HP AdvanceStack
hub from the power source. Electrical shock could result if you
attempt to install the router module without unplugging the hub.
Caution Static electricity can severely damage sensitive electronic components
such as the router module or the SNMP module. While removing the
router module from its packaging and installing it in the hub, follow
these procedures to avoid damage from static electricity:
Equalize any static charge difference between your body and the hub
by using the grounding wrist strap supplied with the router module.
Handle the module by its edges, and avoid touching the components
or the circuitry on the board.
After removing the router module from its packaging and before
connecting it to the SNMP module, make sure it does not sit on a
metal surface. (After the insulating paper between the battery and
the battery clip is removed, placing the router module on a metal
surface can short out the battery and/or damage sensitive
components.)
Installation
3. Install the Router Module.
1-10
