LEDs and Buttons
Status LEDs
The status LEDs are located on the router module’s cover plate.
For information about what is indicated by each of these LEDs, refer to
table 3-1, “Status LEDs”, on the next page. For information on trou-
bleshooting using these LEDs, refer to chapter 4, “Troubleshooting”.
Router Self-test
SNMP Mgt (module) Fault
Hub (LAN) Net Fail
Hub (LAN) Router Rx
Hub (LAN) Router Tx
WAN Net Fail
WAN Rx
WAN Tx
Router Fault
Figure 3-1. Status LEDs
Operation
LEDs and Buttons
3-2
