HP MSR4080 Configuration Guide

125
Displaying and maintaining PIM
Execute display commands in any view and reset commands in user view.
Task
Command
Display register-
tunnel interface
information.
display interface
[
register-tunnel
[ interface-number ] ] [
brief
[
description
|
down
] ]
Display
BSR information in the
PIM-SM domain.
display pim
[
vpn-instance
vpn-instance-name ]
bsr-info
Display information about the
routes used by PIM.
display pim
[
vpn-instance
vpn-instance-name ]
claimed-route
[ source-address ]
Display C-
RP information in the
PIM-SM domain.
display pim
[
vpn-instance
vpn-instance-name ]
c-rp
[
local
]
Display DF
information in the
BIDIR-PIM domain.
display pim
[
vpn-instance
vpn-instance-name ]
df-info
[ rp-address ]
Display PIM information on an
interface.
display pim
[
vpn-instance
vpn-instance-name ]
interface
[ interface-type interface-number ] [
verbose
]
Display PIM neighbor information.
display pim
[
vpn-instance
vpn-instance-name ]
neighbor
[ neighbor-address |
interface
interface-type interface-number |
verbose
] *
Display PIM routing entries.
display pim
[
vpn-instance
vpn-instance-name ]
routing-table
[ group-address [
mask
{ mask-length | mask } ] | source-address
[
mask
{ mask-length | mask } ] |
flags
flag-value |
fsm
|
incoming-interface
interface-type interface-number |
mode
mode-type |
outgoing-interface
{
exclude
|
include
|
match
}
interface-type interface-number |
proxy
] *
Display RP information in the
PIM-SM domain.
display pim
[
vpn-instance
vpn-instance-name ]
rp-info
[ group-address ]
Display statistics for PIM packets.
display pim statistics
Display remote end information
maintained by PIM for ADVPN
tunnel interfaces.
display pim [ vpn-instance
vpn-instance-name
] nbma-link
[ interface {
interface-type interface-number
} ]
PIM configuration examples
PIM-DM configuration example
Network requirements
As shown in Figure 44:
•
OSPF runs on the network.
•
VOD streams are sent to receiver hosts in multicast. The receiver groups of different
organizations form stub networks, and one or more receiver hosts exist on each stub network.
•
The entire PIM domain operates in the dense mode.
•
Host A and Host C are multicast receivers on two stub networks N1 and N2.
•
IGMPv2 runs between Router A and N1, and between Router B, Router C, and N2.
