Configuration prerequisites
Before you configure MLD SSM mappings, complete the following tasks:
•
Configure an IPv6 unicast routing protocol so that all devices in the domain can interoperate at
the network layer.
•
Configure basic MLD features.
Configuration procedure
To configure an MLD SSM mapping:
Step
Command
Remarks
1. Enter system view.
system-view
N/A
2. Enter MLD view.
mld
[
vpn-instance
vpn-instance-name ]
N/A
3. Configure an
MLD SSM
mapping.
ssm-mapping
ipv6-source-address
ipv6-acl-number
By default, no MLD SSM
mappings exist.
Configuring MLD proxying
This section describes how to configure MLD proxying.
Configuration prerequisites
Before you configure the MLD proxying feature, complete the following tasks:
1. Configure any IPv6 unicast routing protocol so that all devices in the domain can interoperate at
the network layer.
2. Determine the router interfaces and host interface based on the network topology.
3. Enable MLD on the router interfaces.
Enabling MLD proxying
When you enable MLD proxying, follow these restrictions and guidelines:
•
You must enable MLD proxying on the receiver-side interfaces.
•
On an interface enabled with MLD proxying, only the mld version command takes effect and
other MLD commands do not take effect.
•
If you enable both MLD proxying and an IPv6 multicast routing protocol on the same device, the
IPv6 multicast routing protocol does not take effect.
To enable MLD proxying:
Step
Command
Remarks
1. Enter system view.
system-view
N/A
2.
Enable IPv6 multicast
routing and enter IPv6 MRIB
view.
ipv6 multicast routing
[
vpn-instance
vpn-instance-name ]
By default, IPv6 multicast routing
is disabled.
