HP Z200 User Manual

ERP compliance mode
This computer provides ERP compliance mode capability.
When enabled, this feature enables the computer to shut down to the lowest possible power state by
removing all power to the system board.
When disabled, the computer powers down conventionally.
When the computer is shut down in ERP compliance mode, it must be powered up with the computer
power button.
Enabling ERP compliance mode
To enable ERP compliance mode:
1.
Press F10 during start up.
2. Using the arrow keys, select the Power>Hardware Power Management>ERP
Compliance Mode, and then select Enable.
3.
Press F10 to accept the change.
4. Select File>Save Change and Exit, and then press F10 to accept the change.
Disabling ERP compliance mode
To disable the ERP compliance mode:
1.
Press F10 during start up.
2. Select Power>Hardware Power Management>ERP Compliance Mode, and then select
Disable.
3.
Press F10 to accept the change.
4. Select File>Save Change and Exit, and then press F10 to accept the change.
Accessibility
HP is committed to developing products, services, and information that is easier to access for all
customers, including customers with disabilities and age-related limitations. HP products with
Windows® 7, Windows Vista® Business, and Microsoft® Windows® XP Professional preinstalled are
designed for accessibility. These products are tested with industry-leading Assistive Technology
products. For more information see
http://www.hp.com/accessibility.
Hyper-threading
This HP computer supports Hyper-threading.
Hyper-Threading Technology (HTT), is an Intel-proprietary technology used to provide process
parallelization . The technology improves processor performance under certain workloads by providing
useful work for execution units that would otherwise be idle. A processor with Hyper-Threading enabled
is treated by the operating system as two processors instead of one. Hyper-threading relies on support
in the operating system as well as the CPU.
ENWW
Computer specifications
13

HP Z200 Specifications

General

Tcase	69.1 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	E3-1240
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	1333 MHz
Maximum internal memory	- GB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD-RW
Card reader integrated	-
Graphics card	Quadro 2000
Power supply type	AC
External drive bays	3 x 5.25\
Internal drive bays	3 x 3.5\
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card family	NVIDIA
Maximum graphics card memory	1.024 GB
Modem (RJ-11) ports	0
PS/2 ports quantity	2
USB 2.0 ports quantity	14
Chassis type	Minitower
Product color	Black
Country of origin	China
Number of 3.5\" bays	3
Bundled software	HP ProtectTools
Operating system installed	Windows 7 Professional
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 85 %
Power supply	400 W
Power supply input voltage	100-240 V
Power supply input frequency	50 - 60 Hz
Certification	ENERGY STAR 5.0
Processor code	SR00K
Processor ARK ID	52273
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	455 mm
Width	178 mm
Height	447 mm
Weight	10400 g
