HP Z200 User Manual

Copying a setup configuration to multiple computers
CAUTION: A setup configuration is model-specific. If source and target computers are not the same
model, file system corruption can result. For example, do not copy the setup configuration from an HP
xw8600 Workstation to an HP Z200 Workstation.
This method takes longer to prepare the configuration diskette, but copying the configuration to target
computers is fast.
A bootable diskette is required for this procedure. If Windows XP is not available to create a bootable
diskette, use the method for copying to a single computer instead (see
Copying a setup configuration to
a single computer on page 40).
1.
Create a bootable diskette or USB media device.
2.
Select a setup configuration to copy.
3.
If you are using a diskette or USB storage device, insert it now.
4.
Restart the computer.
5.
As soon as the computer powers on, press and hold F10 until you enter the Computer Setup (F10)
Utility. If necessary, press Enter to bypass the title screen.
NOTE: If you do not press the F10 key at the appropriate time, you must restart the computer,
and then press and hold the F10 key again to access the utility.
If you are using a PS/2 keyboard, you might see a keyboard error message. Disregard it.
6. Select File>Replicated Setup>Save to Removable Media, and follow the instructions on
the screen to create the configuration diskette or USB media device.
7.
Download a BIOS utility for replicating setup (repset.exe), and copy it to the configuration diskette
or USB media device. To obtain this utility, see
http://www.hp.com/support/files.
8.
Enter the model number of the computer.
9.
On the configuration diskette, create an autoexec.bat file containing repset.exe and cpqsetup.txt.
10.
Power off the computer you are configuring, insert the configuration diskette or USB device, and
then power on the computer. The configuration utility runs automatically.
11.
When the configuration is complete, restart the computer.
ENWW
Desktop management
41

HP Z200 Specifications

General

Tcase	69.1 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	E3-1240
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	1333 MHz
Maximum internal memory	- GB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD-RW
Card reader integrated	-
Graphics card	Quadro 2000
Power supply type	AC
External drive bays	3 x 5.25\
Internal drive bays	3 x 3.5\
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card family	NVIDIA
Maximum graphics card memory	1.024 GB
Modem (RJ-11) ports	0
PS/2 ports quantity	2
USB 2.0 ports quantity	14
Chassis type	Minitower
Product color	Black
Country of origin	China
Number of 3.5\" bays	3
Bundled software	HP ProtectTools
Operating system installed	Windows 7 Professional
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 85 %
Power supply	400 W
Power supply input voltage	100-240 V
Power supply input frequency	50 - 60 Hz
Certification	ENERGY STAR 5.0
Processor code	SR00K
Processor ARK ID	52273
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	455 mm
Width	178 mm
Height	447 mm
Weight	10400 g
