Port Type Quanti
ty
Description
USB port USB 3.0 2 The USB ports allow USB devices to
be connected to the server.
NOTE
Before connecting an external USB device,
check that the USB device functions
properly. A server may operate abnormally
if an abnormal USB device is connected.
Management
network port
RJ45 1 This 1000 Mbps Ethernet port is used
for server management, and supports
10/100/1000 Mbps auto-negotiation.
Serial port RJ45 1 The serial port is used as the system
serial port by default. You can set it as
the iBMC serial port by using the
iBMC command. This port is used for
debugging.
GE electrical
port
RJ45 4/8 ● Each FlexIO card provides four GE
electrical ports. A maximum of
eight GE electrical ports can be
provided through the two FlexIO
cards.
● This 1000 Mbps Ethernet port is
used for FlexIO card, and supports
10/100/1000 Mbps auto-
negotiation.
25GE optical
port
SFP28 4 A FlexIO card can provide a maximum
of four 25GE optical ports.
NOTE
The 25GE optical ports support rate
adaptation to 10GE, and optical modules
of dierent rates are required.
PSU socket - 1/2 Determine the number of PSUs based
on actual requirements, but ensure
that the rated power of the PSUs is
greater than that of the server. You
are advised to congure two PSUs to
ensure reliable device operating.
When one PSU is used, Predicted PSU
Status cannot be set to Active/
Standby on the iBMC WebUI.
2.4 Rear Panel Indicators
Figure 2-13 shows the indicators on the rear panel of the server.
TaiShan 200 Server (Model 2280)
User Guide 2 Components
Issue 09 (2021-01-12) Copyright © Huawei Technologies Co., Ltd. 16
