5.11.4 Logging In to the iBMC WebUI
Log in to the iBMC WebUI by using a browser on the local PC, illustrated here
running Windows 7 and Internet Explorer 11.0.
For details about PC system conguration requirements, see the
TaiShan Rack
Server iBMC User Guide
.
Step 1 Connect the local PC to the iBMC management network port on the server using a
crossover cable or twisted pair cable.
Figure 5-23 shows the network diagram.
Figure 5-23 Network diagram
Step 2 Open Internet Explorer on the local PC.
Step 3 In the address box, enter the iBMC address in the format:
https://
IP address of the iBMC management network port on the server
Example: https://192.168.2.100
Step 4 Press Enter.
The iBMC login page is displayed, as shown in Figure 5-24 and Figure 5-25.
● If the message "There is a problem with this website's security certicate" is displayed,
click Continue to this website (not recommended).
● If the system displays the Security Alert dialog box indicating a certicate error, click
Yes.
TaiShan 200 Server (Model 2280)
User Guide 5 Installation and Conguration
Issue 09 (2021-01-12) Copyright © Huawei Technologies Co., Ltd. 69
