Husqvarna 129l User Manual

WHAT IS WHAT?
What is what on the grass trimmer?
7
8
9
10
11
13
14
17
19
20
12
18
15
16
1
4
5
3
2
5
6
4
1
129L
129LK
129C
21
4
1 Trimmer head
2 Grease filler cap, bevel gear
3 Bevel gear
4 Cutting attachment guard
5 Shaft
6 Shaft coupling
7 Loop handle
8 Throttle trigger
9 Stop switch
10 Throttle trigger lockout
11 Spark plug cap and spark plug
12 Starter housing
13 Starter handle
14 Fuel tank
15 Air filter cover
16 Primer bulb
17 Choke control
18 Drive disc
19 Operator
′ s manual
20
Combination spanner
21 Locking pin
5

Husqvarna 129l Specifications

General

Power Output	0.85 kW
Tube Diameter	25.4 mm
Engine Type	2-stroke
Shaft Type	Straight
Starter System	Smart Start
Fuel Tank Volume	0.34 l
Engine Displacement	27.6 cm³
