21 TECHNICAL DATA 117

21.3 Carburetor

21.3.1 TC 125

Carburetor type MIKUNI TMX 38

Carburetor identification number TMX 38 82

Needle position 3rd position from top

Jet needle 6BFY43-74 (6BFY44-74, 6BFY44-73, 6BFY43-73)

Main jet 480 (490, 500, 520, 540)

Idling jet 45 (42.5/47.5)

Starting jet 80

Needle jet S‑1

Idle air adjusting screw

Open 1.5 turns

21.3.2 Carburetor - basic setting for sandy surfaces (TC 125)

Idle air adjusting screw

Open 1.5 turns

Idling jet 45

Jet needle 6BFY44‑73

Needle position 3rd position from top

Main jet 560

Info

If the engine is not running smoothly, use a smaller main jet.
