11 SERVICE WORK ON THE CHASSIS 57
F00246-10
Main work
(All TC models)
–
Detach retaining tab
. Remove air filter with air filter support.
– Take off air filter from air filter support.
F00247-10
(TX 300)
–
Detach retaining tab
. Remove air filter with air filter support.
– Take off air filter from air filter support.
11.25 Cleaning the air filter and air filter box
Warning
Environmental hazard Hazardous substances cause environmental damage.
– Dispose of oils, grease, filters, fuel, cleaning agents, brake fluid, etc., correctly and in compliance with the applicable
regulations.
Info
Do not clean the air filter with fuel or petroleum since these substances attack the foam.
Preparatory work
– Remove the air filter box cover. ( p. 55)
– Remove the air filter. ( p. 56)
K00518-01
Main work
– Wash the air filter thoroughly in special cleaning liquid and allow it to dry properly.
Air filter cleaning agent ( p. 130)
Info
Only squeeze the air filter to dry it; never wring it out.
– Oil the dry air filter with a high quality filter oil.
Oil for foam air filter ( p. 130)
– Clean the air filter box.
– Clean the intake flange and check it for damage and tightness.
Finishing work
– Install the air filter. ( p. 58)
– Install the air filter box cover. ( p. 56)
