11 SERVICE WORK ON THE CHASSIS 56
11.23 Installing the air filter box cover
F00243-10
(All TC models)
–
Position air filter box cover on collar bushings
and
and push toward
the rear.
–
Engage the air filter box cover in areas
,
and
.
F00244-10
(TX 300)
–
Position air filter box cover on collar bushings
and
and push toward
the rear.
–
Engage the air filter box cover in areas
,
and
.
11.24 Removing the air filter
Note
Engine damage Unfiltered intake air has a negative effect on the service life of the engine.
Dust and dirt will enter the engine without an air filter.
– Never start to use the vehicle without an air filter.
Warning
Environmental hazard Hazardous substances cause environmental damage.
– Dispose of oils, grease, filters, fuel, cleaning agents, brake fluid, etc., correctly and in compliance with the applicable
regulations.
Preparatory work
– Remove the air filter box cover. ( p. 55)
