6 CONTROLS 18
401950-13
(TC 250, TX 300)
The gear positions can be seen in the figure.
The neutral or idle position is between the first and second gears.
6.12 Kick starter
401954-10
Kick starter
is fitted on the right side of the engine.
The top part of the kick starter pivots.
Info
Before riding, swing the top part of the kick starter inward toward the engine.
6.13 Foot brake lever
401956-10
Foot brake lever
is located in front of the right footrest.
The foot brake lever is used to activate the rear brake.
6.14 Plug-in stand (All TC models)
402001-10
Support for plug-in stand
is the left side of the wheel spindle.
The plug-in stand is used to park the motorcycle.
Info
Remove the plug-in stand before riding.
6.15 Side stand (TX 300)
401943-10
The side stand
is on the left side of the vehicle.
