9--1
Cutting speed and
choice of tools
The cutting speed is determined by the blade speed and the head feed speed.
While the head speed is provided by the downstroke movement of the head, the
blade rotation speed can either be fixed or variable. When using the S20DSP, it is
important to select the correct type of blade for the material to be cut. This
chapter explains the limitations and specific applications of the different types of
blades.
Cutting speed
Standard machine
The basic version with 4 pole motor, is provided with the following cutting speeds:
H 1st speed = 15 100 m/min
Inverter technical specifications
Protection rating
IP 31
Vibration and shock
resistance (EN50178)
0.6gnfrom10to50Hz
2gnfrom50to150Hz
Max. relative humidity 93% without condensation or drop--forming
Acceptable Temperature
Range (EN 50178)
For warehouse storing: from --25˚Cto+65˚CFor
operating purposes: from --10˚Cto+40˚C
Max. altitude 1000mt. with no derating
-- single phase: 200V -- 15% to 240V + 10%
Supply
-- three phase: 200V -- 15% to 230V + 10%
380V -- 15% to 460V + 10%
Frequency
50/60 Hz ± 5%
Output voltage Maximum voltage equal to the supply voltage
Output frequency range
0,5 a 320 Hz
Max. transients 150% of electronic speed control rated current for 60
secs.
Frequency resolution
-- Display: 0.1 Hz
-- Analog inputs: 0.1 Hz per 100 Hz max.
Switching frequency Adjustable from 2.2 to 12 Hz max.
9
