Description of machine operation
Angled cu ts 45˚ to the left
" Make sure the vice is positioned to the left of the 0˚ cutting slot;
" slacken the turntable lock/release lever.
The 0, 45 and reference stops for cuts to the right and the 45˚ reference stop
for cuts to the left facilitate rapid head positioning during turntable rotation.
However, the eccentric pin is only correctly positioned if the initial rotation of
the turntable when released is corrected.
