Estimated kerf width compensation
The widths in the chart below are for reference. Differences between installations and material composition may
cause the specific user results to vary from those shown in the table.
Metric
Process 1.5 3 6 10 12 20 25
MS
130A O2-Air 1.803 2.032 2.108 2.642 3.429
80A O2-Air 1.372 1.727 1.905
30A O2-O2 1.346 1.448
SS
130A H35-N2 2.718 2.769 2.896
130A N2-N2 1.829 1.879 2.413
80A F5-N2 1.194
45A F5-N2 0.584 0.381 0.533
45A N2-N2 0.483 0.229 0.152
AL
130A H35-N2 2.718 2.769 2.896
130A Air-Air 2.083 2.083 2.184
45A Air-Air 1.067 1.092 1.245
English
Process 0.060" 0.135" 1/4" 3/8" 1/2" 3/4" 1"
MS
130A O2-Air 0.071 0.080 0.083 0.104 0.135
80A O2-Air 0.054 0.068 0.075
30A O2-O2 0.053 0.057
SS
130A H35-N2 0.107 0.109 0.114
130A N2-N2 0.072 0.074 0.095
80A F5-N2 0.047
45A F5-N2 0.023 0.015 0.021
45A N2-N2 0.019 0.009 0.006
AL
130A H35-N2 0.107 0.109 0.114
130A Air-Air 0.082 0.082 0.086
45A Air-Air 0.042 0.043 0.049
Thickness (in)
Thickness (mm)
