Table 4. IOA assignment rules for MB1, C01-C07
Multi-adapter bridge domain / PCI bridge set IOA assignment rules
MB1, C01 - C07 MB1, C07, C01, C06, C05, C04, C03, C02
Table 5. FRU locations and failing components for Model 270 (Processor features 22A7, 22A8,
22AA, 22AB, 23F4, 23F5, 2423, 2424, 2454)
Position FRU name
Possible failing
component
Type, CCIN, or part number
(use the Type, model, and
part number list to determine
the part number when the
type or CCIN are given.)
Remove and
replace/recovery procedure
C01 PCI card IOA See the Type, model, and part
number list.
Go to Models 270, 800, and
810 - Cards - Concurrent.
C02 PCI card
1. IOP
2. IOA
1. CCIN is 2842 (See page
527), 2843 (See page 527),
or 2844 (See page 527)
2. See the Type, model, and
part number list.
Go to Models 270, 800, and
810 - Cards - Concurrent.
C03 (Short
if 2890 IXS
in C04)
PCI card
1. IOP
2. IOA
1. CCIN is 2842 (See page
527), 2843 (See page 527),
or 2844 (See page 527)
2. See the Type, model, and
part number list.
Go to Models 270, 800, and
810 - Cards - Concurrent.
C04 PCI card
1. Integrated
xSeries Server
(IXS)
2. IOP
3. IOA
1. CCIN is 2890 (See page
527) or 2892 (See page
527)
2. CCIN is 2842 (See page
527), 2843 (See page 527),
or 2844 (See page 527)
3. See the Type, model, and
part number list.
Go to Models 270, 800, and
810 - Cards - Concurrent.
C05 PCI card
1. IOP
2. IOA
1. CCIN is 2842 (See page
527), 2843 (See page 527),
or 2844 (See page 527)
2. See the Type, model, and
part number list
Go to Models 270, 800, and
810 - Cards - Concurrent.
C06 PCI card
1. IOP
2. IOA
1. CCIN is 2842 (See page
527), 2843 (See page 527),
or 2844 (See page 527)
2. See the Type, model, and
part number list.
Go to Models 270, 800, and
810 - Cards - Concurrent.
C07 PCI card IOA See the Type, model, and part
number list.
Go to Models 270, 800, and
810 - Cards - Concurrent.
Analyze hardware problems 233
