Position FRU name
Possible failing
component
Type, CCIN, or part
number (use the Type,
model, and part number
list to determine the part
number when the type or
CCIN are given.)
Remove and
replace/recovery
procedure
C15 PCI card The failing component is
either an:
1. IOP
2. IOA
1. 2842 (See page 527),
2843 (See page 527), or
2844 (See page 527)
2. See Type, model, and
part number list.
Go to Models 840/SB3, FC
8079 (lower half), FC 9079
Cards (concurrent).
CB1 Tower card
v SPCN card
v Tower card
v Service processor
v Multi-adapter bridge (all)
28AA (See page 527) Go to FC 5074, FC 5079,
FC 9079 - Tower card -
CB1.
A01 AC input /
charger
AC module / charger 97H7316 - Single line cord Go to FC 5074, FC 5079,
FC 9079 (with single line
cord) - AC charger - A01.
A02 AC module AC module 21P6347 - Dual line cord Go to Model 830 FC 9074,
Model 840 FC 9079/8079
(with dual line cords) - AC
module (A01, A02).
P01 - P03 Power
supply
Power supply 90H6629 - Single line cord Go to FC 9074, FC 9079,
FC 5074/5079 - Power
supply - P01, P02, and P03.
P01 - P02 Power
supply
Power supply 53P1038 - Dual line cord Go to FC 9074, FC 9079,
FC 5074/5079 - Power
supply - P01, P02, and P03.
PB1 Power board Power board 24L0891 Go to FC 5074, FC 5079,
FC 9079 - Power distribution
board - PB1.
T01 - T04 Battery Battery 97H7318 (This PN includes
all four batteries.)
Go to FC 5074, FC 5079,
FC 9079 - Batteries - T01,
T02, T03, and T04.
HSL cables
on the HSL
ports
HSL cable HSL connection See Type, model, and part
number list.
Go to HSL cables -
Concurrent.
Figure 3. Network Interface Controller (NIC) port locations
Analyze hardware problems 281
