Cover assembly
Final assembly
Control panel assembly - Models 820 and 825: For use by authorized service providers.
Figure 1. Control panel assembly - Models 820 and 825
Table 1. Control panel assembly - Models 820 and 825
Index Part number Units Description
1 NONUM 1 EMC plate
2 NONUM 1 Processor capacity card.
See the Type, model, and
part number list.
384 Hardware (Remove and Replace; Part Locations and Listings)
