Table 4. Final Assembly, Front - Models 830 and SB2 with FC 9074 (continued)
Index Part number Units Description
20 NONUM 1 Shelf, base DASD
21 1621811 3 Screw, M4 (10mm)
22 24L0892 1 Base DASD board stiffener assembly (DB3)
23 24L1029 AR DASD board stiffener assembly (DB1 and DB2)
24 1621838 1 Screw
25 NONUM AR Shelf, DASD
400 Hardware (Remove and Replace; Part Locations and Listings)
