Figure 25. Removing the module from the box
4. Check that all components for assembling the module are in the box. See “Identifying Library Module
components” on page 42.
Figure 26. The module after removal from the box
Attention:
Do not place a module on either the ends or sides as this action can damage the
module.
5. Unlatch the top of the module by using your ngers or a small tool, one on each side of the lid, and
press inward. When the lid is opened, remove it by pulling it forward. See Figure 27 on page 40.
Chapter 3. Installing
39
