Setup and Assembly Manual Page 19

A.10 Connectors on the Back

All connectors are positioned at the right side of the back of the housing, seen from the

operator’s view (i.e. from the front of the scanner).

Picture 6: Back of WideTEK 25

Picture 7: Connectors on the WideTEK 25

1. Power connector and main power switch

2. Serial connector

3. VGA connector

4. Two foot pedal connectors

5. Network cable connector
