Value Function Description
Motor
selection 2
Motor
selection 1
No. of controlled motor
0 0 No.1 motor (default)
0 1 No.2 motor
1 0 No.3 motor
1 1 No.1 motor (default)
44 Brake feedback input
If the function is enabled, the AC drive can continue to run only
after receiving the correct brake feedback signal.
Function Code Parameter Name Setting Range Default
F4-10 DI filter time 0–100 4
It is used to set the sensibility of DI terminals. If the DI terminals are liable to interferences
and may cause malfunction, increase the value of this parameter to enhance the
anti-interference capability. However, increasing the value reduces the sensibility of DI
terminals.
Function Code Parameter Name Setting Range Default
F4-12 Terminal UP/DOWN rate 0.01–100.00 Hz/s 1.00 Hz/s
It is used to set the terminal UP/DOWN rate when the frequency source is terminal
UP/DOWN.
Function Code Parameter Name Setting Range Default
F4-13 AI1 minimum input
0.00 V to F4-15 0.00V
F4-14
AI1 minimum input frequency
-100.00%–100.0% 0.0%
F4-15
AI1 maximum input
F4-13 to 10.00 V 10.00V
F4-16
AI1 maximum input frequency
-100.00%–100.0% 100.0%
F4-17 AI1 filter time
0.00–10.00s 0.10s
These parameters are used to define the relationship between the analog input voltage
and frequency. When the analog input voltage is beyond the value of F4-15 or F4-13, take
the maximum or the minimum value.
When the analog input is current input, 1 mA current equals 0.5 V voltage. In different
applications, 100% of analog input corresponds to different nominal values. Refer to
description of various applications for details.
