Intel S1200V3RP Technical Product Specification

Advanced Management Feature Support (RMM4) Intel® Server Board S1200V3RP TPS
Revision 1.2
70
Figure 17. Intel
®
RMM4 Dedicated Management NIC Installation
Table 24. Enabling Advanced Management Features
Manageability Hardware
Benefits
Intel
®
Integrated BMC
Comprehensive IPMI based base manageability
features
Intel
®
Remote Management Module 4 – Lite
Package contains one module –
 Key for advance Manageability features.
No dedicated NIC for management
Enables KVM and media redirection from onboard
NIC
Intel
®
Remote Management Module 4
Package includes 2 modules –
 key for advance features
 Dedicated NIC (1Gbe) for management
Dedicated NIC for management traffic. Higher
bandwidth connectivity for KVM and media
Redirection with 1Gbe NIC.
If the optional Dedicated Server Management NIC is not used then the traffic can only go
through the onboard Integrated BMC-shared NIC and will share network bandwidth with the
host system. Advanced manageability features are supported over all NIC ports enabled for
server manageability.
7.1 Keyboard, Video, and Mouse (KVM) Redirection
The BMC firmware supports keyboard, video, and mouse redirection (KVM) over LAN. This
feature is available remotely from the embedded web server as a Java applet. This feature is
only enabled when the Intel
®
RMM4 lite is present. The client system must have a Java Runtime
Environment* (JRE*) version 6.0 or later to run the KVM or media redirection applets.
The BMC supports an embedded KVM application (Remote Console) that can be launched from
the embedded web server from a remote console. USB1.1 or USB 2.0 based mouse and
