Platform Management ArchitectureIntel® Server Board SE7520BD2 Technical Product Specification
90 Revision 1.3
Table 45. LAN Channel Specifications
Configuration Capability Options Description/Notes
Channel Access Modes Always-active,
disabled
This option determines when the BMC can be accessed via
IPMI Messaging over LAN.
Number of Sessions One (Essentials) The number of simultaneous sessions that can be supported is
shared across the LAN and serial/modem channels.
Number of Users One (Essentials) User information is a resource that is shared across the LAN
and serial/modem channels.
Configurable User Names No (Essentials) User information is a resource that is shared across the LAN
and serial/modem channels.
Configurable User
Passwords
Yes
Privilege Levels User, Operator,
Administrator
IPMI Message Authentication
Type Support
MD5
Number of LAN Alert
destinations
One (Essentials)
PET Acknowledge support Yes
Gratuitous ARP Support Yes
4.2.6.2 LAN Drivers and Setup
The IPMI-over-LAN feature must be used with the appropriate Intel NIC Driver, and the NIC
correctly configured in order for DPC LAN operation to occur transparently to the operating
system and network applications. If an incorrect driver or NIC configuration is used, it is possible
to get driver timeouts when the IPMI-over-LAN feature is enabled.
4.2.6.3 BIOS Boot Flags
A remote console application can use the IPMI Set System Boot Options command to configure
a set of BIOS boot flags and boot initiator parameters that are held by the management
controller. These parameters include information that identifies the party that initiated the boot,
plus flags and other information that can be used to direct the way booting proceeds after a
system reset or power-up. For example, the system can be configured to boot normally, boot
using PXE, boot to a diagnostic partition, etc.
4.2.6.4 Boot Flags and LAN Console Redirection
The system BIOS includes a LAN Console Redirection capability. This capability can only be
directed to one IP Address at a time. Thus, the boot flags and boot initiator information are also
used to tell the BIOS where to send LAN Console Redirection.
4.2.7 Wake On LAN / Power On LAN and Magic Packet Support
The baseboard supports Wake On LAN / Power On LAN capability using the onboard network
interface chips or an add-in network interface card. An add-in network card can deliver the wake
signal to the baseboard via the PME signal on the PCI bus. The actual support for Magic Packet
and/or packet filtering for Wake On LAN / Power On LAN is provided by the NIC. The
baseboard handles the corresponding wake signal.
