Intel SE7520BD2 Technical Product Specification

Intel® Server Board SE7520BD2 Technical Product SpecificationPlatform Management Architecture
Revision 1.3 Intel Confidential
105
Sensor Name
Sensor
#
Sensor
Type
Event /
Reading
Type
Event Offset
Triggers
Assert /
Deassert
Readable
Value/Offsets
Event Data
PEF
Action
SDR
Record
Type
SCSI Core(1.8v) 12h
Voltage
02h
Threshold
01h
[u,l][ nr, c,nc] As & De Analog R, T
Fault LED
Action
01
Proc1 VCCP 13h
Voltage
02h
Threshold
01h
[u,l][ nr, c,nc] As & De Analog R, T
Fault LED
Action
01
Proc2 VCCP 14h
Voltage
02h
Threshold
01h
[u,l][ nr, c,nc] As & De Analog R, T
Fault LED
Action
01
Tach Fan 1 15h
Fan
04h
Threshold
01h
[u,l][ nr, c,nc] As & De Analog R, T
Fault LED
Action
01
Tach Fan 2 16h
Fan
04h
Threshold
01h
[u,l][ nr, c,nc] As & De Analog R, T
Fault LED
Action
01
Tach Fan 3 17h
Fan
04h
Threshold
01h
[u,l][ nr, c,nc] As & De Analog R, T
Fault LED
Action
01
Tach Fan 4 18h
Fan
04h
Threshold
01h
[u,l][ nr, c,nc] As & De Analog R, T
Fault LED
Action
01
Tach Fan 5 19h
Fan
04h
Threshold
01h
[u,l][ nr, c,nc] As & De Analog R, T
Fault LED
Action
01
Tach Fan 6 1Ah
Fan
04h
Threshold
01h
[u,l][ nr, c,nc] As & De Analog R, T
Fault LED
Action
01
Tach Fan 7 1Bh
Fan
04h
Threshold
01h
[u,l][ nr, c,nc] As & De Analog R, T
Fault LED
Action
01
Tach Fan 8 1Ch
Fan
04h
Threshold
01h
[u,l][ nr, c,nc] As & De Analog R, T
Fault LED
Action
01
Tach Fan 9 1Dh
Fan
04h
Threshold
01h
[u,l][ nr, c,nc] As & De Analog R, T
Fault LED
Action
01
System Event 1Eh
System
Event
12h
Sensor
Specific
6Fh
PEF Action As – Trig Offset – 02
Proc1 IERR 1Fh
Processor
07h
Sensor
Specific
6Fh
IERR As – Trig Offset – 02
Proc2 IERR 20h
Processor
07h
Sensor
Specific
6Fh
IERR As – Trig Offset – 02
Proc1 Thermal
trip
21h
Processor
07h
Sensor
Specific
6Fh
Thermal Trip As – Trig Offset
Fault LED
Action
02
Proc2 Thermal
trip
22h
Processor
07h
Sensor
Specific
6Fh
Thermal Trip As – Trig Offset
Fault LED
Action
02
Proc1 Thermal
Control
23h
Temp
01h
Threshold
01h
[u,l][ nr, c,nc] As & De Analog Trig Offset
Fault LED
Action
01
Proc2 Thermal
Control
24h
Temp
01h
Threshold
01h
[u,l][ nr, c,nc] As & De Analog Trig Offset
Fault LED
Action
01
Diagnostic
Interrupt Button
25h
Critical
Interrupt
13h
Sensor
Specific
6Fh
FP NMI
Button
As – Trig Offset NMI Pulse 02
