Intel® Server Board SE7520BD2 Technical Product Specification BIOS Architecture
Revision 1.3 Intel Confidential
47
Onboard NIC 2 ROM Disabled
Enabled
Enable/Disable OnBoard NIC 2 ROM. Grayed out if device is
disabled.
Onboard SCSI Disabled
Enabled
Enable/Disable OnBoard SCSI.
Onboard SCSI ROM Disabled
Enabled
Enable/Disable OnBoard SCSI ROM. Grayed out if device is
disabled.
Onboard SCSI Mode IM/IME
IS
IM/IME = Integrated
Mirroring/Integrated Mirroring
Enhanced
IS = Integrated Striping
Before changing modes, back up
array data and delete existing arrays,
if any. Otherwise, loss of all data may
occur.
After OS installation with a
selected SCSI RAID mode,
only change this mode
selection if prepared to
rebuild RAID array.
Changing the mode could
damage current OS
installation on RAID
volume.
Grayed out if device is
disabled.
PCI Priority Arbitration Disabled
Enabled
Disabled: round-robin priority scheme
for devices on PCI bus.
Enabled: high/low priority scheme for
devices on PCI bus.
Round-robin verses
alternate high/low priority
scheme: In round-robin
which is default, the device
with the lowest req/gnt pair
gets first chance at the bus.
In this case, the baseboard
devices have
an advantage (reg/gnt 0)
followed by the bottom slots
(req/gnt 1), middle slot
(req/gnt 2), and lastly,
the top slot (req/gnt 3). In
the alternate high/low
scheme, each device gets a
equal opportunity
to be the first device after
the PXH timeslot (PXH has
high priority and others are
low priority).
MMIO above 4GB Disabled
Enabled
Enable/Disable memory mapped I/O
of 64-bit PCI devices to 4GB or
greater address space.
Slot 1 Option ROM Disabled
Enabled
PCI-X 64/100
Slot 2 Option ROM Disabled
Enabled
PCI-X 64/100
Slot 3 Option ROM Disabled
Enabled
PCI 32/33
Slot 4 Option ROM Disabled
Enabled
PCI-Express x4
Slot 5 Option ROM Disabled
Enabled
PCI-Express x8
Slot 6 Option ROM Disabled
Enabled
PCI-X 64/133 2U riser
