Intel® Server Board SE7520BD2 Technical Product SpecificationPlatform Management Architecture
Revision 1.3 Intel Confidential
83
Sensor Name
Sensor
Number
Sensor Type
Event /
Reading
Type
Event Offset
Triggers
Assert /
Deassert
Readable
Value /
Offsets
EventData
Rearm
Standby
Processor 1 Thermal
Control
C0h
Temp
01h
Digital
Discrete
07h
Transitioned to Non-
Critical from OK
As & De – Trig Offset M –
Processor 2 Thermal
Control
C1h
Temp
01h
Digital
Discrete
07h
Transitioned to Non-
Critical from OK
As & De – Trig Offset M –
Processor 1 VRD
Over Temp
C8h
Temp
01h
Digital
Discrete
07h
Transitioned to Non-
Critical from OK
As & De – Trig Offset M –
Processor 2 VRD
Over Temp
C9h
Temp
01h
Digital
Discrete
07h
Transitioned to Non-
Critical from OK
As & De – Trig Offset M –
Processor 1 Vcc D0h
Voltage
02h
Threshold
01h
[u,l][ nr,c,nc] As & De Analog R, T A –
Processor 2 Vcc D1h
Voltage
02h
Threshold
01h
[u,l][ nr,c,nc] As & De Analog R, T A –
CPU Configuration
Error
D8h
Processor
07h
Generic
03h
State Asserted As & De Discrete R, T A -
DIMM 1 E0h
Slot Connector
21h
Sensor
Specific
6Fh
Fault Status
Asserted
Device Installed
Disabled
As – Trig Offset A –
DIMM 2 E1h
Slot Connector
21h
Sensor
Specific
6Fh
Fault Status
Asserted
Device Installed
Disabled
As – Trig Offset A –
DIMM 3 E2h
Slot Connector
21h
Sensor
Specific
6Fh
Fault Status
Asserted
Device Installed
Disabled
As – Trig Offset A –
DIMM 4 E3h
Slot Connector
21h
Sensor
Specific
6Fh
Fault Status
Asserted
Device Installed
Disabled
As – Trig Offset A –
DIMM 5 E4h
Slot Connector
21h
Sensor
Specific
6Fh
Fault Status
Asserted
Device Installed
Disabled
As – Trig Offset A –
DIMM 6 E5h
Slot Connector
21h
Sensor
Specific
6Fh
Fault Status
Asserted
Device Installed
Disabled
As – Trig Offset A –
