Operation and Application

4.2.3 AC+DC Mode

If the output mode select to AC+DC Mode, the instrument will simulate AC and

DC power supply, which can add DC component to AC voltage. Set the output

voltage in the main interface, as shown in the figure below.

Under AC+DC mode, Set the output voltage and frequency of the AC power

supply in the main interface, and set the DC voltage in the configure menu.

Vac: you can set the Vac under the main interface or under the config interface.

DC: set the DC component under the config interface. The setting range is 10%

of rated voltage. DC value can not be set in three-phase balance mode. To set

the three-phase DC component, turn off the balance mode.

NOTE
