System-Related Functions
Copyright ©ITECH Electronic Co., Ltd. 63
keyboard are locked, all buttons can’t be used except Local key, Press [Shift] +
[2] (Lock) once again will relieve key lock function.
5.4 Switching Local/Remote Mode
You can press the [Shift] +[3] (Local) button to change the AC source from
remote to local operation.
After you power on the AC source, it defaults in local mode, all buttons are
enabled. While in remote mode, most buttons are disabled except [Shift] +[3]
(Local) keys. You can switch Local/Remote mode via PC. In addition, the mode
modification will not affect the output parameters.
5.5 Save and Recall Operations
The power system can save up to 10 common parameters in nonvolatile
memory (No. 1 to No. 10) for user to recall conveniently.
The saved parameters include:
⚫ Power supply mode
⚫ Present output mode
⚫ Config menu settings
You can do the save and recall operations by the following two methods.
⚫ Press the composite keys [Shift]+[4] (Save) to save the parameters.
Pressthe composite keys [Shift]+[5] (Recall) to recall the parameters.
⚫ SCPI commands: *SAV and *RCL
Save Operation
The save operation procedures are as follows:
1. Press the composite keys [Shift]+[4] (Save) to enter the parameter save
interface.
2. Select the storage location. up to 10 position can be select.
3. Press [Enter] to save the parameters.
Finished, the saved parameters will be display at the bottom of the interface.
