On/Off: When On is selected, a
trigger signal is output when the
List generates a trigger signal.
(This configuration is displayed
only when the IO function is set to
Trigger2-out)
5.1.1 Menu function
Set OFF Mode Status
This parameter is used to set the status after the power output is off.
⚫ Select to High-Z, After the power output is Off, the dc impedance between
the terminals of the power supply is high, and the resistance value varies
with different models.
⚫ Select to Short, When the power output is Off, the terminals of the power
supply are short-circuited, the voltage is 0.
⚫ Select to Open-Z, After the power output is Off, the power supply is in open
mode, and the internal circuit and external load of the power supply are
disconnected by relay.
Set the buzzer
This item can set the key sound state. If in ON mode, then when you press a
button or occur protection, the power supply will beep. If in OFF mode, the
beeper will not make a sound. The default set is in ON mode.
Set the screen brightness
This item can set the screen brightness. Set the screen brightness within the
range 1 to 10 by pressing number keys on the front panel. The larger the number
is, the higher the screen brightness is. You can also set the screen brightness
by rotating the knob on the front panel.
Restored to Factory Setting
This menu item is used to restore some parameter settings to factory setting
values.
The procedures to set the menu item are as follows.
1. Select the General under system menu.
2. Press Enter in Factory_default_settings. After the parameter settings are
complete and return to main interface.
Set the Power-on State
This parameter determines the state of the AC source after power up.
To Next Page
