12 SPECIFICATIONS
12.2 DIMENSIONS AND WEIGHTS _________________________________________________
Note: Specifications are subject to change without notice.
A Width Of Cut 183 cm 72 In.
B Overall Width 195 cm 76.8 In.
C Maximum Width Transport With Floating Head At 25 mm Height Of Cut 195 cm 76.8 In
D Maximum Height With ROPS Frame Up 206.5 cm 81.3 In.
E Total Length 309.8 cm 122 In
F Wheel Base 154 cm 60.6 In.
G Wheel Track Front 122 cm 48 In.
H
Ground Clearance (Centre Unit Mounting Frame And Deck Set At
Maximum Height Of Cut)
35 mm 1.4 In.
Turning Circle (Cutting Units Centralised) 199 cm 78.3 In.
Weight Of Machine (Transport) 1078 kg. 657 lb.
Maximum Front Axle Loading 776 kg. 1710.8 lb.
Maximum Rear Axle Loading 259 kg. 571 lb.
27” Cutting Deck (Not Including Hydraulic Motor) 72 kg 158.7 lb
Weight Of 28.7 Litres (7.58 US Gallons) (6.3 Imp Gallons) Of Diesel Fuel 20.4 kg. 45.0 lb.
