SPECIFICATIONS 12
12.1 ENGINE SPECIFICATION _______________________________________________
Note: Specifications are subject to change without notice.
Model D1105-E4B
Type: Vertical, Water Cooled, 4-cycle Diesel engine
Number of Cylinders 3
Bore and Stroke 78 mm x 78.4 mm (3.07 in. x 3.09 in.)
Total Displacement 1.123 liters (68.53 cu.in.)
Combustion Chamber Indirect Injection
SAE Net Intermittent kW / rpm
H.P. (SAEJ1349) (HP / rpm)
18.5 kW @ 3000 rpm
(24.8 HP @ 3000 rpm)
SAE Net Continuous kW / rpm
H.P. (SAEJ1349) (HP / rpm)
15.4 kW @ 3000 rpm
(20.7 HP @ 3000 rpm)
Maximum Speed: 3150 ± 50 rpm (No load)
Idle Speed: 1650 ±25 rpm
Firing order 1-2-3
Direction of Rotation Counter-clockwise (viewed from flywheel side)
Injection Pump
Bosch MD type mini pump
Injection Pressure
13.73 MPa (194kgf/cm², 1991 psi)
Injection Timing (Before T.D.C.)
0.35 rad(18°)
Compression Ratio 24:1
Fuel: Diesel to BS EN590 or ASTM D975 (“Ultra Low Sulphur”)
Lubrication (API Class) Above CF grade
Oil Sump Capacity: 5.1 litres (1.35 US Gals)
Dimensions
(length x width x height)
497.8 mm x 396.0 mm x 608.7 mm
(19.60 in. x 15.59 in. x 23.96 in.)
Dry Weight kg (lbs) 93.0 kg (205 lbs)
Starting System Cell starter with glow plug
Starter Motor 12V, 1.2kW
Charging Generator 12V, 40 Amp
