46
VTX A8 | Rigging Manual
10 - DISASSEMBLING AN A8 ARRAY
STEPS:
• Safely lower the entire array to a workable height.
• Press the Release Buttons on all four lower cabinets to unlock the rigging mechanisms. This enables the bottom four cabinets
to collapse back to the 10-degree position once the array is lowered to the ground.
• Attach the VT to the bottom cabinet. Connect the two points at either the front or rear, then lift the other side of the VT and
attach the other two points.
10.1 OPEN THE ANGLE LOCKS AND ATTACH THE VT
1
2
3
3
1
2
