VTX A8 | Rigging Manual
14.4 VTX B18 GND
Each Base Plate ships with four stabilization feet that connect to the lowest B18 in an array. The feet attach to the B18 using the four
corner quick release pins and provide additional stability for taller arrays. The feet are only needed when the Base Plate is used in
conjunction with the VTX B18. When the Base Plate is used with other VTX subwoofers like the VTX B28, different accessories
may be needed, such as the VTX B28 GND.
STEPS:
• While the B18 is still on the ACC dolly, remove each of the four corner QRPs, slide the feet in place and restore the QRP.
• With all four feet in place, use the rear two handles on the B18 to flip the it onto the feet.
• Remove the ACC dolly. Additional B18 cabinets can be stacked on top if needed.
1
2
3
