# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
5-8
5.5 ELECTRICAL PARTS LIST
******************************
SW REGULATOR BOARD ASSEMBLY <01>
PW1 LPA10119-01D1 SW.REGULATOR BOARD ASSY
IC5101 STR-F6552 IC
IC5301 L5431 IC
or MM1431AT IC
Q5301 2SD1819A/RS/-X TRANSISTOR
or 2PC4081/R/-X TRANSISTOR
or 2SC4081/RS/-X TRANSISTOR
Q5302 DTA114EU TRANSISTOR
or PDTA114EU TRANSISTOR
or RN2302 TRANSISTOR
or UN5111 TRANSISTOR
D5001 RBV-406 BRIDGE DIODE
D5101 SARS01 DIODE
D5102 AU01Z FR DIODE
or PG104RS FR DIODE
or 1SR153-400-T2 FR DIODE
or 10ELS2 FR DIODE
or ERA18-02-T2 FR DIODE
D5103 1SS133 DIODE
or 1SS270A DIODE
D5201 AK04 DIODE
or 1S4 SB DIODE
or 11EQS04 SB DIODE
D5202 FML-12S FR DIODE
or FCF06A20 FR DIODE
or ER602FCT FR DIODE
or SF5LC20U FR DIODE
or YG901C2 FR DIODE
D5204 1SR153-400-T2 FR DIODE
or PG104RS FR DIODE
or 10ELS2 FR DIODE
or ERA18-02-T2 FR DIODE
D5206 FMB-24 BARRIER DIODE
or FSQ05A04B SB DIODE
or SF5SC4 SB DIODE
or YG801C04 SB DIODE
or SB640FCT SB DIODE
D5207 FMB-24 BARRIER DIODE
or FSQ05A04B SB DIODE
or SB640FCT SB DIODE
or SF5SC4 SB DIODE
or YG801C04 SB DIODE
D5208 AK04 DIODE
or 1S4 SB DIODE
or 11EQS04 SB DIODE
D5210 AU01Z FR DIODE
or ERA18-02-T2 FR DIODE
or PG104RS FR DIODE
or 1SR153-400-T2 FR DIODE
or 10ELS2 FR DIODE
D5211 AU01Z FR DIODE
or ERA18-02-T2 FR DIODE
or PG104RS FR DIODE
or 1SR153-400-T2 FR DIODE
or 10ELS2 FR DIODE
D5301 MTZJ15A ZENER DIODE
or RD15ES/B1/-T2 ZENER DIODE
D5303 MTZJ7.5A ZENER DIODE
or RD7.5ES/B1/-T2 ZENER DIODE
D5304 1SS133 DIODE
or 1SS270A DIODE
D5305 MTZJ27C ZENER DIODE
or RD27ES/B3/-T2 ZENER DIODE
D5306 MTZJ2.7B ZENER DIODE
or RD2.7ES/B2/-T2 ZENER DIODE
D5307 1SS133 DIODE
or 1SS270A DIODE
D5308 1SS133 DIODE
or 1SS270A DIODE
D5309 1SS133 DIODE
or 1SS270A DIODE
D5310 1SS133 DIODE
or 1SS270A DIODE
D5311 1SS133 DIODE
or 1SS270A DIODE
D5312 1SS133 DIODE
or 1SS270A DIODE
R5101 QRG02GJ-683 OMF RESISTOR 68kØ,2W
R5102 QRE141J-100Y RESISTOR 10Ø,1/4W
R5103 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W
R5104 QRE141J-681Y RESISTOR 680Ø,1/4W
R5105 QRT01DJ-R47X MF RESISTOR 0.47Ø,1W
R5107 QRE141J-684Y RESISTOR 680kØ,1/4W
R5108 QRE121J-470Y RESISTOR 47Ø,1/2W
R5302 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W
R5303 NRVA02D-123X CMF RESISTOR 12kØ,1/10W
R5304 NRVA02D-302X CMF RESISTOR 3kØ,1/10W
R5305 NRSA02J-223X MG RESISTOR 22kØ,1/10W
!
R5306 QRZ9005-470X FUSI RESISTOR 47Ø,1/4W
R5307 NRSA02J-221X MG RESISTOR 220Ø,1/10W
R5308 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R5309 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W
R5310 QRL02DJ-821X OMF RESISTOR 820Ø,2W
R5311 NRSA02J-473X MG RESISTOR 47kØ,1/10W
R5313 NRSA02J-561X MG RESISTOR 560Ø,1/10W
R5314 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R5316 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R5317 NRSA02J-333X MG RESISTOR 33kØ,1/10W
!
C5001 QFZ9073-683 F CAPACITOR 0.068µF,250V
!
C5002 QFZ9051-333 F CAPACITOR 0.033µF,250V
!
C5004 QCZ9071-222 CAPACITOR 0.0022µF,250V
C5007 QEZ0374-826 E CAPACITOR 82µF,400V
C5102 QEMU1VM-276 E CAPACITOR 27µF,35V
C5103 QCZ0302-330Z CAPACITOR 33pF,1kV
C5104 QFLC1HJ-471Z F CAPACITOR 470pF,50V
C5105 NCB21HK-223X CAPACITOR 0.022µF,50V
C5106 QCZ0212-472 CAPACITOR 0.0047µF,1kV
C5201 QEMU0JM-227 E CAPACITOR 220µF,6.3V
C5202 QEMT1CM-827 E CAPACITOR 820µF,16V
C5203 QETN1CM-227 E CAPACITOR 220µF,16V
C5204 QEMT1AM-228 E CAPACITOR 2200µF,10V
C5205 QETN1AM-227 E CAPACITOR 220µF,10V
C5206 QEMU1EM-187 E CAPACITOR 180µF,25V
C5207 QETN2AM-475 E CAPACITOR 4.7µF,100V
C5208 QEMU1HM-186 E CAPACITOR 18µF,50V
C5210 QEMT1AM-687 E CAPACITOR 680µF,10V
C5211 QETN1AM-227 E CAPACITOR 220µF,10V
C5212 QEMT1AM-228 E CAPACITOR 2200µF,10V
To Next Page
